Frame: Pinarello 2023 Dogma F Disk Speedster BOB
Color: Black
Brake Type: Flat-Mount disc brake
Size: Size 56 (56.5cm). 565mm Effective Top Tube. Stack - 570.2mm. Reach - 390.7mm. Head Tube 149.5mm. Recommend buyer confirm and research full geometry online.
Condition: Per prior owner claims, this item has less than 800 miles on it. No cracks or carbon defects were identified through a thorough visual inspection. The cosmetic imperfections to highlight include: There is a small mark on the non drive side chain stay, see picture #17. We have attempted to show all noticeable imperfections in specific close-up pictures, however other minor imperfections and light signs of use may exist.
Groupset Compatibility: Frame can be setup for Di2, EPS, eTap, or mechanical groupsets. This frame was previously setup with an eTap groupset. Other frame/cable stops may be needed for Di2 or mechanical setups.
Bottom bracket: ITA (Italian) bottom bracket shell type. No bottom bracket currently installed or included. We have a handful of lightly used basic bottom brackets on hand, let us know what you need and we can try to ship the frame with the right bottom bracket installed. Additionally, CyclingUpgrades is a Wheels Manufacturing, and a Ceramicspeed Authorized Dealer, if you prefer to have the frame setup with a certain Wheels Manufacturing, or Ceramicspeed bottom bracket we can add and install it at an additional cost before shipping - message with inquiries/requests.
Steerer Length: 65mm of steerer above the top tube. 30mm of spacers below the stem plus the headset cover. We do have an option available to safely extend the steerer tube by 15-18mm - message us for additional details.
Seatpost: Pinarello Dogma F seatpost included. Compatible with round or oval saddle rails.
Dropout Spacing: Front 12mm Thru Axle x 100mm, Rear 12mm Thru Axle x 142mm.
Weight: 1864 grams as pictured.
What's included: Frame, fork, headset, seatpost, rear derailleur hanger, thru axles
